ESD Epoxy Primer Conductive 2 Gal Kit (Special Order)

The Concrete Protector's Epoxy Primer Conductive is a two-component, solvent-based epoxy primer formulated for priming concrete and masonry substrates prior to applying a suitable static control top coat. Delivering excellent abrasion resistance, static dissipative properties, and strong adhesion at 400 psi, it provides a reliable conductive base layer for ESD flooring systems in environments where electrostatic discharge control is required. Retains conductive properties regardless of temperature and performs well at all humidity levels.

Read more
Regular price $131.99
Shipping calculated at checkout.

Have questions about this product? Call our experts at (877) 743-9732.

Product Description

The Concrete Protector's Epoxy Primer Conductive is a two-component, solvent-based epoxy primer formulated for priming concrete and masonry substrates prior to applying a suitable static control top coat. Delivering excellent abrasion resistance, static dissipative properties, and strong adhesion at 400 psi, it provides a reliable conductive base layer for ESD flooring systems in environments where electrostatic discharge control is required. Retains conductive properties regardless of temperature and performs well at all humidity levels.

(Allow 7-10 business days for shipping on special order items.)

Key Benefits:

  • Excellent static dissipative properties for ESD flooring systems
  • Excellent abrasion and chemical resistance
  • Strong adhesion of 400 psi with concrete failure confirmation
  • Retains conductive properties regardless of temperature
  • Performs well at all humidity levels

Cure Schedule (at 75°F):

  • Pot Life: 3-5 hours
  • Tack Free: 2-4 hours
  • Recoat/Topcoat: 15-24 hours
  • Light Foot Traffic: 3-5 hours
  • Full Cure: 2-7 days

Physical Properties:

  • Coverage: 229-267 sq ft per gallon at 6-7 mils wet thickness
  • Film Thickness: 6-7 mils wet (yields 3 mils dry)
  • Adhesion: 400 psi (concrete failure, no delamination)
  • Viscosity: Clear 500-900 cps / Black 250-400 cps
  • Abrasion Resistance: 36.0 mg loss (Taber CS-17, 1,000g load, 500 cycles)
  • Impact Resistance: Gardner Impact direct 50 in. lb. (passed)
  • Flexibility: No cracks on 1/8" mandrel
  • VOC: Clear 3.55 lbs per gallon / Black 3.74 lbs per gallon
  • Shelf Life: 6 months (unopened)

Limitations:

  • All new concrete must cure at least 30 days before application
  • Slab on grade requires a moisture barrier
  • Substrate temperature must be 50 degrees F above dew point
  • If temperatures are below 60 degrees F, allow material to induct for 15 minutes before applying
  • Do not topcoat until electrical resistance is 10^6 ohms or lower (may require up to 24 hours)
  • Too thick of an application may result in product failure
  • Colors may be affected by high humidity, chemicals, temperatures, or sodium vapor lighting
  • Color may vary from batch to batch

Application:

  1. Pre-mix Part A and Part B separately
  2. Combine 1 part Part A with 1 part Part B; mix thoroughly with a low-speed drill until well blended and streak free
  3. Apply to surface using a brush or 3/8" nap roller

Mix Ratio: 1:1 by volume

Coverage: 229-267 sq ft per gallon

Standard Color: Semi-Clear

Other Colors: Black

Packaging: 2 Gal Kit
